The industry’s first family of Controller Area Network (CAN) transceivers including various automotive Grade 0 qualified parts is now available from Microchip Technology Inc. The ATA65XX family adds six new devices to Microchip’s CAN portfolio.
The new family supports the recently established CAN FD (Flexible Data-rate) protocol for up to five Mbit/s communication speed and the new CAN PN (Partial Networking) standard for improved energy efficiency of vehicles. Therefore, the devices are fully compliant with the ISO 118980-2/5/6, 11898-2:2016 and the SAE J2962-2 standards. The ATA6562, ATA6563, ATA6564, ATA6565, and ATA6566 build the industry’s first automotive Grade 0 qualified CAN/CAN-FD transceiver family with an ambient temperature rating of -40° to 150°C.
The family also provides a CAN partial networking transceiver including a window watchdog. All devices in the family are approved by major car manufacturers for use without the external Common Mode Choke (CMC) that is required for most CAN transceivers.
“Microchip has one of the strongest and most complete CAN portfolios in the industry,” said Matthias Kaestner, vice president of Microchip’s automotive division. “Our transceivers ensure reliable communication in the harsh automotive environment with less external components and minimal board space which leads to lower system cost.”
All family members include wake-up capability via CAN bus with dual wake up pattern according to ISO11898-2:2016. A modern vehicle contains more than 70 Electronic Control Units (ECU) with CAN interface. This feature avoids unwanted power-up sequences, leading to significant energy savings and reduced emissions.
For more information about the ATA65XX Family, visit: http://www.microchip.com/CAN
Development support
The ATA65xx family is supported by the ATA656x-EK development kit, ATAB6570A development kit and the ATA6563 Click Board, all of which are available today.
Availability
Microchip provides the new family in SO 8/14 and DFN8/14 packages with wetable flanks, ready for automatic optical solder-joint inspection.
The following products in the ATA65xx family are available today:
- The ATA6562/63/64/66 is available in an SO8 package or DFN8 package with wetable flanks in 10,000 unit quantities.
- The ATA6565 is available in a DFN14 package with wetable flanks in 10,000 unit quantities.
- The ATA6570 is available in an SO14 package in 10,000 unit quantities.
For additional information, contact any Microchip sales representative or authorised worldwide distributor, or visit Microchip’s website. To purchase products mentioned in this press release, go to the new, easier-to-navigate and mobile-optimised microchipDIRECT or contact one of Microchip’s authorised distribution partners.
