TDK presents the EPCOS E10 EM series, a new range of insulated SMT transformers that are suitable for various DC/DC converters topologies and gate driver circuits in e-mobility and industrial electronics.
Specifications
- Available in 4 models with basic winding insulation
- N1 / N2 creepage ≥ 6 mm, clearance ≥ 5.5 mm
- Depending on the model, the turns ratio is between 1:0.76 and 4:1
- The working voltage of 500 VRMS and reinforced insulation of 300 VRMS
- Extremely compact design with a dimension of 11.7 x 13.15 x 11.35 mm3
- Ferrite Core IVInZn
- SMD Gullwing pins, Triple Insulated wire, Non-Conductive Pick, and Place cap on top
- High reproducibility and reliability as a result of highly automated production & A01 final inspection
- Qualified in accordance with AEC-0200 Rev. D
Main Field of Applications
DC/DC Converters and gate driver circuits in e-mobility and industrial electronics
Main Features and Benefits
- Compact dimensions of just 11.7×13.15×11.35 mm3
- Compliance with the IEC 60664-1 standard for clearance & creepage
- Qualified in accordance with AEC-Q200 Rev. D
