Power Integrations, the leader in gate-driver technology for medium- and high-voltage inverter applications, announced a range of galvanically isolated transformers that provide the correct voltage and power for the company’s SCALE-iDriver family of gate drivers. The combination delivers a simple, robust and cost-efficient DC-DC converter solution that does not require additional voltage regulation, reducing system cost and development time. The SIT12xxI transformer and SCALE-iDriver ICs are fully UL and VDE approved.
The new SIT12xxI transformers feature an innovative insulated construction that improves reliability and delivers a high isolation capability combined with low coupling capacitance. Devices suit both 600 V and 1200 V two-channel SCALE-iDriver gate drivers with 5 V (SIT1253I) or 15 V (SIT1217I) input voltages and 25 V output voltage. The shrouded transformers weigh only 9 g and require no potting, but nonetheless pass tests for extended field life and high resistance to shock and vibration. They meet UL1446, UL61800-5-1, IEC61800-5-1, IEC61558-1 and IEC61558-2-16.
“The SCALE-iDriver family of IGBT and SiC-MOSFET driver ICs employs Power Integrations’ FluxLink magneto-inductive bi-directional communications technology to ensure reinforced galvanic isolation between the primary and secondary sides, setting a new standard in isolation integrity and stability. By providing a perfectly matched transformer we reduce system development, qualification and certification time, and also simplify the purchasing process. The new design of the transformer construction targets industrial applications, delivering a rugged and lightweight isolated DC-DC solution while minimizing common-mode noise coupling,” said Thorsten Schmidt, product marketing manager for gate-driver products at Power Integration.
