iWave Systems, an embedded technology computing company, is pleased to announce the launch of the AGILEX System on Module.
The System on Module supports two variants of Intel Agilex FPGA SoC devices, which includes Agilex F-Series and Agilex I-Series
- iW-RainboW-G43 – Intel Agilex R31BSoC SOM: AGI 019, AGI 023, AGI 022, AGI 027
- iW-RainboW-G51 – Intel Agilex R24C SoC SOM: AGF 006, AGF 008, AGF 012, AGF 014, AGF 022, AGF 023, AGF 027
Agilex SoC/FPGAs enable customized acceleration and connectivity for a wide range of computing & bandwidth-intensive applications such as data center, networking, and edge applications while providing an improvement in performance with 40% lower power consumption. Furthermore, it delivers 2x fabric performance per watt and integrates the ARM Cortex A53 Core application processor to provide high system integration.
Available in a 120mm x 90mm form factor, The system on modules is the industry first to offer a pin-compatible System on Modules covering a majority of the F-Series and the I-Series.
The Agilex System on Module is power-packed with up to 2.7M programmable logic elements for processing huge/complex data algorithms. Besides this, the SoM supports primary interface and components, such as Gigabit Ethernet, USB2.0 port, JTAG, UART, onboard DDR4 and eMMC flash for storage, high-speed transceivers, and more.
Complementing the Agilex SoC on-chip resources, the SoM provides for:
- Up to 64 FGT transceiver channels (up to 32G NRZ / 58G PAM4)
- Up to 8 FHT transceiver channels (up to 58G NRZ / 116G PAM4)
- On SoM PTP & SyncE Network Synchronizers
- SmartVID to adjust voltage as per the temperature and performance requirements
- Up to 138 LVDS/276 SE IOs
“The two new System on Modules featuring the new Intel Agilex SoC are built to enable companies in developing leading-edge computing applications by providing flexible and feature-rich platforms”, said Ahmed Shameem M H, Hardware Project Manager at iWave Systems.” Through the years of remote work and supply chain challenges, a system on a module-based product approach seems to be the preferred route. iWave has designed these SoMs to suit various applications by including a plethora of interfaces.”
To enable quick prototyping and speed up development, iWave supports customers by providing reference designs in the form of development kits and sophisticated up-to-date software packages.
