Introduction
MORNSUN latest open-frame AC DC Converter LOF series can meet the standard of the medical industry, and comes with the power of 120/225/350W. The power density of LOF products is upgraded, and the dimension is reduced by 59% ((LOF120: 3″×2″×1.2″ (1W/cm3), LOF225: 4″×2″×1″ (1.7W/cm3), LOF350: 5 “×3″×1” (1.4W/cm3)) compared with conventional products. It will provide more layout space for customers.
The safety regulation of LOF series input-output meets international medical regulations 2xMOPP, and LOF series with active PFC function will be safer and more reliable in practical application. It meets medical electrical equipment standards (IEC/EN/ES60601-1), industrial standards (IEC/EN/UL62368, IEC/EN61558) and home appliance standards (IEC/EN60335)
Application
Low leakage current (<0.1mA) is suitable for BF medical equipment and non-patient contacting devices, and it also meets industrial application standards.
Typical application: Hemodialysis
Features
- Input voltage range: 85-264VAC 100-373VDC (LOF120/225)
90-264VAC 127-373VDC (LOF350)
- Operating temperature range: -40℃ to 70℃
- Compact size
LOF120：3″×2″×1.2″ (1W/cm3)
LOF225：4″×2″×1″ (1.7W/cm3)
LOF350：5″×3″×1″ (1.4W/cm3)
- I/O isolation voltage: 4000VAC
- Active PFC (PF value: 0.95/230VAC)
- Input-output: 2×MOPP
- No-load power consumption < 3W
- Output short circuit, over-current, over-voltage, over-temperature protection
- Available in system of Safety Class I/II
- Efficiency up to 95%
- Operating altitude up to 5000m
- EMI meets CISPR32/EN55032 CLASS B
- Meet medical electrical equipment standards (IEC/EN/ES60601-1), industrial standards (IEC/EN/UL62368, IEC/EN61558) and home appliance standards (IEC/EN60335)
(EN60335/61558/62368, UL62368 pending)
- With conformal coating
- With Fan（LOF225/350）
