A research group consisting of scientists from Tomsk Polytechnic University, Germany and Venezuela proved the existence of chemical bonds between gallium and oxygen. This discovery will allow manufacturing superconducting nanoelectronics based on gallium selenide, which has never been achieved by any research team in the world. The study was published in Semiconductor Science and Technology.
A promising area of modern materials science is the study of two-dimensional (2-D) materials, i.e. thin films consisting of one or several atomic layers. 2-D materials, due to their electrical superconductivity and strength, could be a basis for new nanoelectronics. Optical applications in nanoelectronics require advanced materials capable of generating electron fluxes upon light irradiation. Gallium selenide (GaSe) is a 2-D semiconductor that can handle this problem most efficiently.
“Some research teams abroad have tried to create electronic devices based on GaSe. However, despite extensive theoretical studies of this material, which were published in major scientific journals, the stability of the material in real devices remained unclear,” says Prof. Raul Rodriguez, the Department of Lasers and Lighting Engineering.
The research team studied GaSe by means of Raman spectroscopy and X-ray photoelectron spectroscopy, proving the existence of chemical bonds between gallium and oxygen. The scientists revealed that GaSe oxidizes quickly in air and loses its electrical conductivity, which is necessary for creating nanoelectronic devices.
“GaSe monolayers become oxidized almost immediately after being exposed to air. Further research of GASe stability in air will allow methods to protect it and maintain its optoelectronic properties,” the authors write.
According to Prof. Rodriguez, preserving the unique properties of GaSe entails placing it in a vacuum or inert environment. For example, it can be applied in encapsulated devices that are vacuum manufactured and then covered with a protective layer, eliminating air penetration. This method can be used to produce next-generation optoelectronics, detectors, light sources and solar batteries. Such devices of ultra-small size will have very high quantum efficiency, i.e., they will be able to generate large electron fluxes under small external exposure.
